Spring SQL Injection
Guide: Examples and
Prevention

stackhawk

StackHawk|February 6, 2021

SQL injection attacks can be devastating. In this post, find examples of these attacks and best practices to prevent a Spring SQL injection.

Introduction

As hackers find increasingly creative ways to attack applications, organizations must try to stay one step ahead in protecting themselves, even from the most common types of attacks and across a variety of frameworks.

Let’s start this post with a few definitions.

SQL Injection

SQL injection is a common way that hackers and users with malicious intentions attempt to hack applications. In an SQL injection, they “inject” values into a database query in order to gain visibility into the database’s structure and eventually gain access to personal data stored in the database.

Spring Boot

Spring Boot is part of the Spring Framework. The Spring Framework is a well-known framework for Java development, and Spring Boot is the framework’s solution for convention over configuration-based software development. This post is about preventing SQL injections in Spring Boot. Let’s now elaborate on the above.

What Is an SQL Injection?

As explained in our overview of SQL injection post, an SQL injection is a popular attack vector on the client’s input into a software system. For instance, let’s look at a website that contains a form for the user to fill. An attacker can use the form’s content maliciously to fetch data from the database. They do this by entering specific data with control characters as input to manipulate the database to execute arbitrary code. As stated on OWASP‘s website, “A successful SQL injection exploit can read sensitive data from the database, modify database data (Insert/Update/Delete), execute administration operations on the database (such as shutdown the DBMS), recover the content of a given file present on the DBMS file system, and in some cases issue commands to the operating system.”

Why Is It Important to Mitigate SQL Injection?

There are many factors that make an SQL injection something you should take the time to mitigate.

Here are a few:

  • Client data is the most prevalently used type of data for generating database queries.

  • Hackers can use this attack against any SQL database.

  • A low level of expertise is needed to execute this type of attack.

What Is Spring Boot?

The Spring Framework is a very popular Java framework for developing enterprise and web applications. Originally created in 2005 by Pivotal, it is still going strong today and is the most popular Java framework on the market. Over the years, different modules were added to the core Spring container: authentication and authorization, data access, transaction management, etc. One of the most popular modules is Spring Boot. It provides preconfigured defaults and modules for the core Spring Framework. Thus abstracting the complexity of manual configuration away and allowing rapid development of applications. This “batteries included”/”ready to develop”/”no setup” approach is what made this module so popular. As of today, almost all new projects developed on Spring will be based on Spring Boot (except possibly those for large enterprises or those that need to have manual customization of the base containers).

Java SQL Injection

As Spring Boot is written in Java, we need to discuss SQL injections in Java first. In general, in most cases, preventing a Java SQL injection is the same as preventing a Spring Boot SQL injection. As stated above, an SQL injection is basically an attack that incorporates special control characters into a valid input for malicious intents. We’ll give a few examples of such inputs here and three ways to process them:

  • The wrong way to process (which allows an attacker to execute an SQL injection)

  • The right way to process them in Java (preventing any SQL injection attempts)

  • And the right way with Spring

Example 1

The Wrong Way

Let’s assume we want to fetch a user’s data from the users table.

public List
  getUserByUserId(String userId)
  throws SQLException {
    String sql = "select "
      + "first_name,last_name,username "
      + "from users where userid = '"
      + userId
      + "'";
    Connection c = dataSource.getConnection();
    ResultSet rs = c.createStatement().executeQuery(sql);
}

If we want to fetch data for a user with id=20, the resulting SQL query will look like this:

select first_name,last_name,username from users where userId = 20 ;

This is a valid SQL query that will produce the expected output. However, if an attacker is able to provide the input of 20 or 1=1 and we run the code as is, the resulting SQL query will become as follows:

select first_name,last_name,username from users where userId = 20  or '1'='1';

Which will result in returning all the users in the database to the client. This is a Boolean-based SQL injection. If we use plain JDBC as in the example above, the proper way to construct the query is with prepared statements. With prepared statements, the SQL engine caches the final query before executing it and treats any data we insert into it as plain input omitting any control characters. Note that using JPA or other ORMs without prepared statements with bound parameters won’t protect you from an SQL injection.

The Right Way

public List getUserByUserId(String userId)
  throws SQLException {
    String sql = "select "
      + "first_name,last_name,username "
      + "from users where
      + userId = ?";
    Connection c = dataSource.getConnection();
    PreparedStatement p = c.prepareStatement(sql);
    p.setString(20, userId);
    ResultSet rs = p.executeQuery(sql));
}

The Spring Boot Way

Another right way to execute this SQL query in Spring Boot is to use the NamedParameterJdbcTemplate class. This method has an additional benefit of providing more clarity by replacing the question marks in the query with meaningful names:

Map<String, Object> params = new HashMap<>();
integer userId = 20;
    String sql = "select "
      + "first_name,last_name,username "
      + "from users where
      + userId = :userId";
params.put("userId", userId);
template.update(sql,params);

Example 2

Another type of SQL injection is the Union SQL injection:

https://someurl.com/user?name=="Bilbo' union all select 1, concat(username,permission)  from permissions where '1'='1"

If we naively use GET parameters input in an SQL query, the attacker will be able to fetch data from the permissions table.

The way to mitigate such a scenario is by using prepared statements with bound parameters as described above.

Stored Procedures

A different approach to sanitizing the input and preventing Spring Boot SQL injections is to use stored procedures instead of plain SQL query. The database engine sanitizes any parameter passed to a stored procedure. Here’s an example of executing the query in the first example via a stored procedure:

String userId = 20
try {
  CallableStatement cs = connection.prepareCall("{call sp_getUserByUserId(?)}");
  cs.setInt(userId, userid);
  ResultSet results = cs.executeQuery();
  // … result set handling
} catch (SQLException se) {
  // … logging and error handling
}
Find and Fix Security Vulnerabilities

Conclusion

sql-injection-prevention-spring-img-3 image

SQL injections are a common and high-risk attack vector. However, as we’ve seen above, it’s fairly easy to mitigate this risk with prepared statements, bound parameters, and stored procedures. As long as you’re following the best practices, hackers won’t be able to execute SQL injections in your application.

This post was written by Alexander Fridman. Alexander is a veteran in the software industry with over 11 years of experience. He worked his way up the corporate ladder and has held the positions of Senior Software Developer, Team Leader, Software Architect, and CTO. Alexander is experienced in frontend development and DevOps, but he specializes in backend development.
